Quectel BC95

NB-IoT Module Series
BC95 Hardware Design
BC95_Hardware_Design Confidential / Released 30 / 51
A reference circuit is shown as below.
Module
NETLIGHT
4.7K
47K
2.2K
VBAT
Figure 15: Reference Design for NETLIGHT
“*” means under development.
NOTE
