LTE Standard Module Series
EM05-G Hardware Design
EM05-G_Hardware_Design 15 / 69
1.
1)
Within operating temperature range, the module is 3GPP compliant.
2.
2)
Within extended temperature range, the module remains the ability to establish and maintain SMS,
data transmission, etc. There is no unrecoverable malfunction. There are also no effects on radio
spectrum and no harm to radio network. Only one or more parameters like P
out
might reduce in their
value and exceed the specified tolerances. When the temperature returns to normal operating
temperature levels, the module will meet 3GPP specifications again.
⚫ Support (U)SIM card: 1.8/3.0 V
⚫ Compliant with ISO/IEC 7816-3
⚫ Compliant with USB 2.0 specification (slave only), the data transfer
rate can reach up to 480 Mbps
⚫ Used for AT command communication, data transmission, GNSS
NMEA output, software debugging and firmware upgrade
⚫ Support USB serial drivers for Windows 7/8/8.1/10, Linux 2.6–5.10,
Android 4.x–10.x
⚫ Main antenna (ANT_MAIN)
⚫ Rx-diversity antenna/GNSS antenna (ANT_DRX/ANT_GNSS)
Support LTE/WCDMA Rx-diversity
⚫ Protocol: NMEA 0183
⚫ Data update rate: 1 Hz
⚫ Compliant with 3GPP TS 27.007, 3GPP TS 27.005
⚫ Quectel enhanced AT commands
⚫ M.2 Key-B
⚫ Size: (42 ±0.15) mm × (30 ±0.15) mm × (2.3 ±0.2) mm
⚫ Weight: approx. 6.0 g
⚫ Operating temperature range: -30 °C to +70 °C
1)
⚫ Extended temperature range: -40 °C to +85 °C
2)
⚫ Storage temperature range: -40 °C to +90 °C
All hardware components are fully compliant with EU RoHS directive
