LTE Standard Module Series
EM05-G Hardware Design
EM05-G_Hardware_Design 48 / 69
1)
If this function is required, please contact Quectel for more details.
4.7. Configuration Pins
EM05-G provides four configuration pins, which are defined as below.
Table 21: Configuration Pins List of M.2 Specification
Table 22: Configuration Pins of the Module
Config_0
(Pin 21)
Config_1
(Pin 69)
Config_2
(Pin 75)
Config_3
(Pin 1)
Module Type and
Main Host Interface
Port
Configuration
GND
GND
NC
NC
Quectel defined
NA
Pin No.
Pin Name
Description
1
CONFIG_3
Not connected internally
21
CONFIG_0
Connected to GND internally
69
CONFIG_1
Connected to GND internally
75
CONFIG_2
Not connected internally
NOTE
