Quectel EM05-G User Manual

LTE Standard Module Series
EM05-G Hardware Design
EM05-G_Hardware_Design 19 / 69
7
USB_DP
AIO
USB 2.0 differential data (+)
8
W_DISABLE1#
DI, OD
Airplane mode control.
Active LOW.
1.8/3.3 V
9
USB_DM
AIO
USB 2.0 differential data (-)
10
WWAN_LED#
DO, OD
RF status indication LED.
Active LOW.
VCC
11
GND
Ground
12
Notch
Notch
13
Notch
Notch
14
Notch
Notch
15
Notch
Notch
16
Notch
Notch
17
Notch
Notch
18
Notch
Notch
19
Notch
Notch
20
PCM_CLK*
DIO, PD
PCM clock
1.8 V
21
CONFIG_0
DO
Connected to GND
internally.
22
PCM_DIN*
DI, PD
PCM data input
1.8 V
23
WOWWAN#
DO, OD
Wake up the host.
Active LOW.
1.8/3.3 V
24
PCM_DOUT*/
VDD_IO
1)
DO,
PD/PO
PCM data output/Antenna
tuner supply power.
1.8 V
25
DPR*
DI, PU
Dynamic power reduction.
High level by default.
1.8 V
26
W_DISABLE2#*
DI, OD
GNSS disable control.
Active LOW.
1.8/3.3 V
27
GND
Ground
28
PCM_SYNC*
DIO, PD
PCM data frame sync
1.8 V
29
NC
NC
30
USIM1_RST
DO, PD
(U)SIM1 card reset
USIM1_VDD
1.8/3.0 V
