2 Product Concept
2.1. General Description
EM05 is a series of LTE/UMTS/HSPA+ wireless communication module with receive diversity. It provides
data connectivity on LTE-FDD, LTE-TDD, DC-HSDPA, HSPA+, HSDPA, HSUPA, WCDMA and CDMA
networks. It also provides optional GNSS functionality to meet customers’ specific application demands.
EM05 contains three variants: EM05-CE, EM05-CML and EM05-E*. Customers can select a dedicated
type based on the region or operator. The following table shows the frequency bands of EM05 series
module.
Table 1: Frequency Bands of EM05 Series Module
EM05 can be applied in the following fields:
 Rugged Tablet PC and Laptop Computer
 Remote Monitor System
 Handheld mobile device
 Wireless POS System
 Smart Metering System
 Other Wireless Terminal Devices
Modules
LTE Bands
WCDMA
Bands
CDMA
Band
Rx-diversity
GNSS
(Optional)
EM05-CE
FDD: B1/B3/B5/B8
TDD: B38/B39/B40/B41
WCDMA:
B1/B8
BC0
Supported
GPS,
GLONASS,
BeiDou,
Galileo,
QZSS
EM05-CML
TDD: B38/B39/B40/B41
/
/
Supported
EM05-E*
FDD: B1/B3/B7/B8/B20/B28
TDD: B38
WCDMA:
B1/B8
/
Supported
