6.7. RF Receiving Sensitivity
The following tables show conducted RF receiving sensitivity of EM05 series module.
Table 30: EM05-CML Conducted RF Receiving Sensitivity
Table 31: EM05-CE Conducted RF Receiving Sensitivity
Frequency
Primary
Diversity
SIMO
3GPP (SIMO)
LTE-TDD B38 (10M)
-97.5dBm
-99.0dBm
-101.2dBm
-96.3dBm
LTE-TDD B39 (10M)
-99.0dBm
-100.2dBm
-102.5dBm
-96.3dBm
LTE-TDD B40 (10M)
-98.0dBm
-98.2dBm
-101.3dBm
-96.3dBm
LTE-TDD B41 (10M)
-97.5dBm
-99.0dBm
-101.0dBm
-94.3dBm
Frequency
Primary
Diversity
SIMO
3GPP (SIMO)
LTE-TDD B38 (10M)
-97.5dBm
-99.0dBm
-101.2dBm
-96.3dBm
LTE-TDD B39 (10M)
-99.0dBm
-100.2dBm
-102.5dBm
-96.3dBm
LTE-TDD B40 (10M)
-98.0dBm
-98.2dBm
-101.3dBm
-96.3dBm
LTE-TDD B41 (10M)
-97.5dBm
-99.0dBm
-101.0dBm
-94.3dBm
LTE-FDD B1 (10M)
-98.5dBm
-99.0dBm
-101.7dBm
-97.0dBm
LTE-FDD B3 (10M)
-98.5dBm
-99.5dBm
-102.2dBm
-94.0dBm
LTE-FDD B5 (10M)
-98.7dBm
-100.2dBm
-102.7dBm
-95.0dBm
LTE-FDD B8 (10M)
-98.5dBm
-100.0dBm
-102.5dBm
-94.0dBm
WCDMA B1
-109.5dBm
\
\
-106.7dBm
WCDMA B8
-110.0dBm
\
\
-103.7dBm
CDMA BC0
-109.0dBm
\
\
-104dBm
