Quectel EP06 User Manual

31 / 50
Table 18: RF Output Power
The following tables show conducted RF receiving sensitivity of EP06 series module.
Table 19: EP06-A Conducted RF Receiving Sensitivity
The following tables show conducted RF receiving sensitivity of EP06 series module.
Table 20: EP06-E Conducted RF Receiving Sensitivity
Frequency
Max.
Min.
WCDMA bands
24dBm+1/-3dB
<-50dBm
LTE FDD bands
23dBm±2dB
<-40dBm
LTE TDD bands
23dBm±2dB
<-40dBm
Frequency
Primary
Diversity
SIMO
1)
3GPP (SIMO)
WCDMA B2
-108.5dBm
/
/
-106.7dBm
WCDMA B4
-108.0dBm
/
/
-103.7dBm
WCDMA B5
-109.5dBm
/
/
-104.7dBm
LTE-FDD B2 (10M)
-97.7dBm
/
-100.7dBm
-94.3dBm
LTE-FDD B4 (10M)
-97.2dBm
/
-100.2dBm
-96.3dBm
LTE-FDD B5 (10M)
-97.7dBm
/
-102.2dBm
-94.3dBm
LTE-FDD B7 (10M)
-96.2dBm
/
-98.7dBm
-94.3dBm
LTE-FDD B12 (10M)
-97.2dBm
/
-101.7dBm
-93.3dBm
LTE-FDD B13 (10M)
-97.7dBm
/
-100.7dBm
-93.3dBm
LTE-FDD B25 (10M)
-98.0dBm
/
-100.9dBm
-92.8dBm
LTE-TDD B26 (10M)
-98.4dBm
/
-102.1dBm
-93.8dBm
LTE-TDD B30 (10M)
-96.7dBm
/
-99.6dBm
-95.3dBm
LTE-TDD B66 (10M)
-97.6dBm
/
-100.7dBm
-95.8dBm
Frequency
Primary
Diversity
SIMO
1)
3GPP (SIMO)
WCDMA B1
-109.5dBm
/
/
-106.7dBm
