45 / 50
6 Storage and Packaging
6.1. Storage
The module is stored in a vacuum-sealed bag. It is rated at MSL 3, and its storage restrictions are listed
below.
1. Shelf life in the vacuum-sealed bag: 12 months at < 40ºC/90%RH.
2. After the vacuum-sealed bag is opened, devices must stored at <10% RH.
As the plastic container cannot be subjected to high temperature, it should be removed from devices
before high temperature (120ºC) baking. If shorter baking time is desired, please refer to
IPC/JEDECJ-STD-033 for baking procedure.
6.2. Packaging
The EP06 Mini PCIe is packaged in a tray. Each tray contains 10pcs of modules. The smallest package of
EP06 Mini PCIe contains 100pcs
NOTE
