Quectel EP06 User Manual

30 / 50
4 Electrical and Radio Characteristics
4.1. General Description
This chapter mainly describes the following electrical and radio characteristics of EP06:
 Power supply requirements
 RF characteristics
 GNSS receiver
 Current consumption
 ESD characteristics
4.2. Power Supply Requirements
The input voltage of EP06 is 3.3V±9%, as specified by PCI Express Mini CEM Specifications 1.2. And the
power supply of EP06 should be able to provide sufficient current up to 2A at least. The following table
shows the power supply requirements of EP06.
Table 17: EP06 Power Supply Requirements
4.3. RF Characteristics
The following table shows the RF output power of EP06 module.
Parameter
Description
Min.
Typ.
Max.
Unit
VCC
Power Supply
3.1
3.3
4.4
V
