Quectel EP06 User Manual

36 / 50
The following table shows the current consumption of the EP06-E.
Table 24: EP06-E Current Consumption
LTE-FDD B3+B28 @21.12dBm
TBD
mA
LTE-FDD B7+B5 @21.29dBm
TBD
mA
LTE-FDD B7+B7 @21.33dBm
TBD
mA
LTE-FDD B7+B8 @21.3dBm
TBD
mA
LTE-FDD B7+B20 @21.32dBm
TBD
mA
LTE-FDD B7+B28 @21.33dBm
TBD
mA
LTE-FDD B5+B32 @20.91dBm
TBD
mA
LTE-FDD B8+B32 @20.88dBm
TBD
mA
LTE-FDD B20+B32 @20.88dBm
TBD
mA
LTE-FDD B28+B32 @21.1dBm
TBD
mA
LTE-TDD B38+B38 @21.3dBm
TBD
mA
LTE-TDD B40+B40 @20.99dBm
TBD
mA
LTE-TDD B41+B41 @21.25dBm
TBD
mA
WCDMA
voice call
WCDMA B2 CH9400@23.5dBm
658.8
mA
WCDMA B4 CH1412 @23.1dBm
655.2
mA
WCDMA B5 CH4407 @23.1dBm
532.9
mA
Parameter
Description
Conditions
Typ.
Unit
Sleep state
AT+CFUN=0 (USB disconnected)
1.69
mA
WCDMA PF=64 (USB disconnected)
2.65
mA
WCDMA PF=128 (USB disconnected)
2.69
mA
WCDMA PF=256 (USB disconnected)
2.41
mA
WCDMA PF=512 (USB disconnected)
2.66
mA
