Quectel L89 R2.0 User Manual

GNSS Module Series
L89_R2.0_EVB_User_Guide 10 / 25
Table 1: List of Accessories
2.2. Connecting Cables and Antenna to EVB
The connection between the EVB and its accessories is shown in the figure below. For detailed information,
refer to the instruction sheet with the EVB kit.
Figure 2: EVB and Accessories Assembly
Items
Description
Quantity
EVB
Evaluation Board
Size: 80 mm × 100 mm
1
USB Cable
Micro-USB cable
1
GNSS Antenna
L89 R2.0 active GNSS antenna
Request the antenna datasheet from Quectel Technical
Supports.
1
Instruction Sheet
The document provides instructions on how to connect the
EVB and its accessories, detailed information on EVB
accessories, etc.
1
Others
Bolts and coupling nuts
4 pairs
