Quectel L89 R2.0 User Manual

GNSS Module Series
L89_R2.0_EVB_User_Guide 19 / 25
GPS satellite
BeiDou satellite
GLONASS satellite
Galileo satellite
QZSS satellite
NavIC satellite
⚫ PRN 30 CNR is 39 dB/Hz.
⚫ Column in bright red means that the navigation data of the
satellite are in use.
⚫ PRN 1 CNR is 21 dB/Hz.
⚫ Column in light red means that the navigation data of this
satellite are not in use.
⚫ Longitude (unit: degree)
⚫ Latitude (unit: degree)
⚫ Altitude (MSL) (unit: m)
⚫ Altitude (EPH) (unit: m)
⚫ Receiver Speed (unit: km/h)
⚫ Horizontal Dilution of Precision
⚫ Position Dilution of Precision
⚫ Fix Mode
⚫ UTC Date and Time
⚫ Total Duration (unit: second)
⚫ Last TTFF (unit: second)
⚫ Quality Indicator
⚫ Total Times
⚫ Fixed Points
⚫ RTK Float
⚫ RTK Fixed
⚫ CEP 95 (unit: m)
⚫ RMS (unit: m)
