7.3. Power Consumption
Table 42: BG950A-GL Power Consumption
BG950A-GL (Power Supply: 3.3 V, Room Temperature)
Description
Conditions
Avg.
Max.
Unit
Leakage
Power-off @ USB/UART disconnected
1.35
-
μA
PSM
PSM @ USB/UART disconnected
1.43
-
μA
Rock bottom
AT+CFUN=0 @ Sleep mode
54
-
μA
Sleep mode
(USB disconnected)
LTE Cat M1 DRX = 1.28 s
1.09
-
mA
LTE Cat NB1 DRX = 1.28 s
2.14
-
mA
LTE Cat M1
e-I-DRX = 81.92 s
@ PTW = 2.56 s, DRX = 1.28 s
0.137
-
mA
LTE Cat NB1
e-I-DRX = 81.92 s
@ PTW = 2.56 s, DRX = 1.28 s
0.138
-
mA
Idle state
LTE Cat M1 DRX = 1.28 s
15.62
-
mA
LTE Cat NB1 DRX = 1.28 s
16.21
-
mA
LTE Cat M1
e-I-DRX = 81.92 s
@ PTW = 2.56 s, DRX = 1.28 s
15.03
-
mA
LTE Cat NB1
e-I-DRX = 81.92 s
@ PTW = 2.56 s, DRX = 1.28 s
14.64
-
mA
LTE Cat M1 data
transfer
(GNSS OFF)
LTE HD-FDD B1 @ 23.19 dBm
223.62
552.28
mA
LTE HD-FDD B2 @ 23.25 dBm
208.00
500.24
mA
LTE HD-FDD B3 @ 23.10 dBm
194.05
447.41
mA
LTE HD-FDD B4 @ 23.08 dBm
195.35
450.43
mA
