Quectel LPWA Series User Manual

LPWA Module Series
BG950A-GL&BG951A-GL_Hardware_Design
67
/ 84
LTE HD-FDD B5 @ 22.99 dBm
189.81
441.28
mA
LTE HD-FDD B8 @ 23 dBm
204.86
493.13
mA
LTE HD-FDD B12 @ 22.91 dBm
185.70
420.22
mA
LTE HD-FDD B13 @ 22.43 dBm
177.34
389.41
mA
LTE HD-FDD B18 @ 22.86 dBm
186.41
432.36
mA
LTE HD-FDD B19 @ 23.06 dBm
190.79
446.71
mA
LTE HD-FDD B20 @ 23.05 dBm
197.48
471.20
mA
LTE HD-FDD B25 @ 23.22 dBm
216.49
528.12
mA
LTE HD-FDD B26 @ 22.89 dBm
193.69
456.99
mA
LTE HD-FDD B27 @ 22.83 dBm
184.06
423.48
mA
LTE HD-FDD B28 @ 22.68 dBm
181.85
419.20
mA
LTE HD-FDD B66 @ 23.01 dBm
196.32
461.80
mA
LTE Cat NB1 data
transfer
(GNSS OFF)
LTE HD-FDD B1 @ 23.16 dBm
215.81
553.23
mA
LTE HD-FDD B2 @ 23.25 dBm
205.67
536.87
mA
LTE HD-FDD B3 @ 23.15 dBm
188.92
478.17
mA
LTE HD-FDD B4 @ 23.21 dBm
183.31
477.15
mA
LTE HD-FDD B5 @ 23.01 dBm
176.99
445.83
mA
LTE HD-FDD B8 @ 23.09 dBm
197.90
530.05
mA
LTE HD-FDD B12 @ 23.01 dBm
175.02
441.49
mA
LTE HD-FDD B13 @ 22.67 dBm
162.38
406.59
mA
LTE HD-FDD B17 @ 23.01 dBm
168.53
416.74
mA
LTE HD-FDD B18 @ 23.19 dBm
166.79
425.41
mA
LTE HD-FDD B19 @ 22.61 dBm
174.28
461.28
mA
LTE HD-FDD B20 @ 22.71 dBm
174.52
443.72
mA
LTE HD-FDD B25 @ 23.36 dBm
200.58
512.86
mA
LTE HD-FDD B28 @ 23.12 dBm
176.39
446.66
mA
