Quectel LPWA Series User Manual

LPWA Module Series
BG950A-GL&BG951A-GL_Hardware_Design
68
/ 84
Table 43: BG951A-GL Power Consumption
LTE HD-FDD B66 @ 23.10 dBm
189.72
475.43
mA
BG951A-GL (Power Supply: 3.3 V, Room Temperature)
Description
Conditions
Avg.
Max.
Unit
Leakage
Power-off @ USB/UART disconnected
2.1
-
μA
PSM
PSM @ USB/UART disconnected
TBD
-
μA
Rock bottom
AT+CFUN=0 @ Sleep mode
TBD
-
mA
Sleep mode
(USB disconnected)
LTE Cat M1 DRX = 1.28 s
TBD
-
mA
LTE Cat NB1 DRX = 1.28 s
TBD
-
mA
LTE Cat M1
e-I-DRX = 81.92 s
@ PTW = 2.56 s, DRX = 1.28 s
TBD
-
mA
LTE Cat NB1
e-I-DRX = 81.92 s
@ PTW = 2.56 s, DRX = 1.28 s
TBD
-
mA
Idle state
LTE Cat M1 DRX = 1.28 s
TBD
-
mA
LTE Cat NB1 DRX = 1.28 s
TBD
-
mA
LTE Cat M1
e-I-DRX = 81.92 s
@ PTW = 2.56 s, DRX = 1.28 s
TBD
-
mA
LTE Cat NB1
e-I-DRX = 81.92 s
@ PTW = 2.56 s, DRX = 1.28 s
TBD
-
mA
LTE Cat M1 data transfer
(GNSS OFF)
LTE HD-FDD B1 @ dBm
TBD
TBD
mA
LTE HD-FDD B2 @ dBm
TBD
TBD
mA
LTE HD-FDD B3 @ dBm
TBD
TBD
mA
LTE HD-FDD B4 @ dBm
TBD
TBD
mA
LTE HD-FDD B5 @ dBm
TBD
TBD
mA
LTE HD-FDD B8 @ dBm
TBD
TBD
mA
LTE HD-FDD B12 @ dBm
TBD
TBD
mA
