Table 2: Directory List of Signed Image and Source Image
if venus.* is not signed, then camera and video cannot work. Use the signed image to rebuild android
system image.
Path of venus.*:
LINUX/android/vendor/qcom/proprietary/prebuilt_HY11/target/product/msm8909/system/etc/firmware/ven
us.*
2. Copy signed images to individual image file path.
Extract moveSecDat.bat.tar; copy moveSecDat.bat to work directory (containing boot_images/, common/,
Signed Image
Source Image
common\tools\sectools\secimage_output\
8909\cmnlib\cmnlib.mbn
trustzone_images/build/ms/bin/MAZAANAA/cmnlib.mbn
common\tools\sectools\secimage_output\
8909\widevine\widevine.mbn
trustzone_images/build/ms/bin/MAZAANAA/widevine.mbn
common\tools\sectools\secimage_output\
8909\keymaster\keymaster.mbn
trustzone_images/build/ms/bin/MAZAANAA/keymaster.mb
n
common\tools\sectools\secimage_output\
8909\wcnss\wcnss.mbn
wcnss_proc/build/ms/bin/SCAQMAZ/reloc\wcnss.mbn
common\tools\sectools\secimage_output\
8909\mba\mba.mbn
modem_proc/build/ms/bin/8909.genns.prod\mba.mbn
common\tools\sectools\secimage_output\
8909\modem\modem.mbn
modem_proc/build/ms/bin/8909.genns.prod\qdsp6sw.mbn
common\tools\sectools\secimage_output\
8909\venus\venus.*
LINUX/android/vendor/qcom/proprietary/prebuilt_HY11/tar
get/product/msm8909/system/etc/firmware/venus.*
common\tools\sectools\secimage_output\
8909\appsbl\ emmc_appsboot.mbn
LINUX\android\out\target\product\msm8909\emmc_appsb
oot.mbn
common\tools\sectools\secimage_output\
8909\qsee\ tz.mbn
trustzone_images\build\ms\bin\MAZAANAA\tz.mbn
common\tools\sectools\secimage_output\
8909\sampelapp\ sampelapp.mbn
trustzone_images\build\ms\bin\MAZAANAA\
sampelapp.mbn
common\tools\sectools\secimage_output\
8909\rpm\rpm.mbn
rpm_proc\build\ms\bin\8909\pm8909\rpm.mbn
common\tools\sectools\secimage_output\
8909\sbl1\ sbl1.mbn
boot_images\build\ms\bin\8909\emmc\unsigned\sbl1.mbn
common\tools\sectools\secimage_output\
8909\prog_emmc_ddr\prog_emmc_fireh
ose_8909_ddr.mbn
boot_images\build\ms\bin\8909\emmc\unsigned\prog_em
mc_firehose_8909_ddr.mbn
