Quectel SC200R Series User Manual

Smart Module Series
SC200R&SC262R_Series_Hardware_Design 100 / 124
Table 49: SC200R-NA Current Consumption
B2 (HSUPA) @ max. power
566.8
mA
B4 (HSUPA) @ max. power
566.2
mA
B5 (HSUPA) @ max. power
493.1
mA
B8 (HSUPA) @ max. power
522.3
mA
LTE data transfer
LTE-FDD B1 @ max. power
728.1
mA
LTE-FDD B2 @ max. power
723
mA
LTE-FDD B3 @ max. power
732.4
mA
LTE-FDD B4 @ max. power
758.7
mA
LTE-FDD B5 @ max. power
615.5
mA
LTE-FDD B7 @ max. power
826.9
mA
LTE-FDD B8 @ max. power
642.7
mA
LTE-FDD B20 @ max. power
677.9
mA
LTE-FDD B28 @ max. power
764.5
mA
LTE-TDD B38 @ max. power
448.4
mA
LTE-TDD B40 @ max. power
432.7
mA
LTE-TDD B41 @ max. power
444.2
mA
Description
Conditions
Typ.
Unit
OFF state
Power down
8
μA
WCDMA
supply current
Sleep (USB disconnected) @ DRX = 6
3.698
mA
Sleep (USB disconnected) @ DRX = 8
2.711
mA
Sleep (USB disconnected) @ DRX = 9
2.566
mA
LTE-FDD
supply current
Sleep (USB disconnected) @ DRX = 6
6.698
mA
Sleep (USB disconnected) @ DRX = 8
3.509
mA
