Quectel SC200R Series User Manual

Smart Module Series
SC200R&SC262R_Series_Hardware_Design 79 / 124
5 GNSS
SC200R series module integrates a IZat™ GNSS engine (GEN 8C) which supports multiple positioning
and navigation systems including GPS, GLONASS, Galileo and BeiDou. With an embedded LNA, the
module provides greatly improved positioning accuracy.
5.1. GNSS Performance
The following table lists the GNSS performance of the module in conduction mode.
Table 33: GNSS Performance
SC200R-WF/SC262R-WF does not support GNSS.
Parameter
Description
Typ.
Unit
Sensitivity
Cold start
-146
dBm
Reacquisition
-158
dBm
Tracking
-158
dBm
TTFF
Cold start
30.8
s
Warm start
21
s
Hot start
3.3
s
Static Drift
CEP-50
< 2.5
m
NOTE
