About the Document
Revision History
Version
Date
Author
Description
1.0
2019-12-30
Arsene TONG
Initial
1.1
2020-09-09
Jasper LAI/
Jamie SHI
1. Updated SC200R-EM frequency bands (Chapter
2.1/6.1):
Added B4 in LTE-FDD
Deleted B39 in LTE-TDD
Added B4 in WCDMA
2. Added Galileo in supported GNSS (Chapter
2.1/2.2/5/6.3).
3. Added a note for the wakeup of LDO6_1V8 during
sleep mode (Chapter 3.3).
4. Updated Wi-Fi output power and added Wi-Fi
receiving sensitivity (Chapter 4.1.1).
5. Added BT transmitting and receiving performance
(Chapter 4.2.1).
6. Added GNSS performance data (Chapter 5.1).
7. Added current consumption of SC200R-CE/-NA
(Chapter 7.4).
8. Added RF output power of SC200R-NA (Chapter
7.5).
9. Added RF receiving sensitivity of SC200R-CE/-NA
(Chapter 7.6).
10. Updated the maintenance clearance between the
module and other components to at least 5 mm
(Chapter 8.2).
11. Updated general description of storage,
manufacturing and soldering (Chapter 9.1/9.2).
12. Added package weight of the module (Chapter 9.3).
1.2
2021-06-02
Kevin ZHOU/
Jamie SHI
1. Chapter 4.1.1: Updated Wi-Fi receiving sensitivity.
2. Chapter 7.4: Updated current consumption of
