Quectel SC200R Series

Smart Module Series
SC200R&SC262R_Series_Hardware_Design 18 / 124
Table 3: SC200R-EM Frequency Bands
Table 4: SC200R-NA Frequency Bands
GNSS
GPS: 1575.42 ±1.023 MHz
GLONASS: 1597.5–1605.8 MHz
BeiDou: 1561.098 ±2.046 MHz
Galileo: 1575.42 ±1.023 MHz
Mode
Frequency
LTE-FDD
B1/B2/B3/B4/B5/B7/B8/B20/B28
LTE-TDD
B38/B40/B41
WCDMA
B1/B2/B4/B5/B8
GSM
850/900/1800/1900 MHz
Wi-Fi 802.11a/b/g/n
2412–2472 MHz
5180–5825 MHz
Bluetooth 4.2 LE
2402–2480 MHz
GNSS
GPS: 1575.42 ±1.023 MHz
GLONASS: 1597.5–1605.8 MHz
BeiDou: 1561.098 ±2.046 MHz
Galileo: 1575.42 ±1.023 MHz
Mode
Frequency
LTE-FDD
B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B66/B71
LTE-TDD
B41
WCDMA
B2/B4/B5
Wi-Fi 802.11a/b/g/n
2412–2472 MHz
5180–5825 MHz
Bluetooth 4.2 LE
2402–2480 MHz
GNSS
GPS: 1575.42 ±1.023 MHz
GLONASS: 1597.5–1605.8 MHz
BeiDou: 1561.098 ±2.046 MHz
Galileo: 1575.42 ±1.023 MHz
