Quectel SC200R Series User Manual

Smart Module Series
SC200R&SC262R_Series_Hardware_Design 34 / 124
CSI0_LN2_N
160
AI
Camera MIPI
data 2 (-)
CSI0_LN2_P
199
AI
Camera MIPI
data 2 (+)
CSI0_LN3_N
161
AI
Camera MIPI
data 3 (-)
CSI0_LN3_P
200
AI
Camera MIPI
data 3 (+)
CAM0_MCLK
74
DO
Clock of camera
V
OL
max = 0.45 V
V
OH
min = 1.35 V
1.8 V power
domain.
CAM1_MCLK
75
DO
Clock of camera
CAM0_RST
79
DO
Reset of camera
CAM0_PWDN
80
DO
Power down of
camera
CAM1_RST
81
DO
Reset of camera
CAM1_PWDN
82
DO
Power down of
camera
CAM_I2C_SCL
83
OD
I2C clock of
camera
Externally pull them
up to 1.8 V.
CAM_I2C_SDA
84
OD
I2C data of camera
CAM2_MCLK
165
DO
Clock of camera
V
OL
max = 0.45 V
V
OH
min = 1.35 V
1.8 V power
domain.
CAM2_RST
164
DO
Reset of camera
CAM2_PWDN
163
DO
Power down of
camera
DCAM_I2C_SCL
166
OD
I2C clock of
camera
Externally pull them
up to 1.8 V.
DCAM_I2C_SDA
205
OD
I2C data of camera
Keypad Interfaces
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
PWRKEY
114
DI
Turns on/off the
module
V
IL
max = 0.63 V
V
IH
min = 1.17 V
Pulled up to 1.8 V
internally.
Active low.
RESET_N
225
DI
Resets the
module
Disabled by default
and can be enabled
via software
configuration.
