Quectel SC200R Series User Manual

Smart Module Series
SC200R&SC262R_Series_Hardware_Design 39 / 124
1.
1)
When the module is in sleep mode, LDO6_1V8 wakes up periodically or randomly. Considering the
actual requirement for power consumption during sleep mode, you can use either LDO6_1V8 or an
external LDO for power supply. For lower power consumption, use an external LDO instead.
2.
2)
SC200R-WF/SC262R-WF does not support GNSS.
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
VIB_DRV_N
28
PO
Vibration motor
driver output
control
V
O
= 1.2–3.1 V
I
O
max = 175 mA
Connect it to the
negative pole of the
motor.
Indication Interface
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
CHG_LED
195
AO
Indicates the
module's
charging status
I
O
max = 5 mA
Other Interfaces
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
NFC_CLK
181
DO
NFC clock
NFC_CLK_REQ
182
DI
NFC clock
request
CBL_PWR_N
186
DI
Initiates
power-on when
grounded
The module cannot
be turned off when
this pin is pulled
down. If it is not
used, keep it open.
Reserved Pins
Pin Name
Pin No.
Comment
RESERVED
150–152, 173–175, 178–180, 183, 184, 192, 232, 242, 246,
249, 252–254, 257, 263, 270
Keep these pins
open.
NOTE
