QUICK BTQSeries INSTALLATION AND USER’S MANUAL - REV003A
6
1 - Information about the product
MODELS BTQ 1806512 BTQ 1806524 BTQ 1808512 BTQ 1808524 BTQ 1810512 BTQ 1810524
Propeller type 2 Counter rotating (technopolymer)
Tunnel Ø
185 mm
(7” 18/64)
185 mm
(7” 18/64)
185 mm
(7” 18/64)
185 mm
(7” 18/64)
185 mm
(7” 18/64)
185 mm
(7” 18/64)
Motor power 3.3 kW 3.3 kW 4.3 kW 4.3 kW 6.3 kW 6.3 kW
Voltage 12 V 24 V 12 V 24 V 12 V 24 V
Fuse 275 A CNL DIN 175 A CNL DIN 400 A CNL DIN 275 A CNL DIN 400 A CNL DIN 275 A CNL DIN
Thrust 65 kgf (55.1 lb) 65 kgf (55.1 lb) 85 Kgf (187.4 lb) 85 Kgf (187.4 lb) 105 Kgf (231.5 lb)105 Kgf (231.5 lb)
Weight 17.6 kg (38.8 lb) 17.8 Kg (39.2 lb) 17.9 kg (39.4 lb) 20.5 kg (45.2 lb) 27.5 kg (60.6 lb) 25.1 Kg(55.3 lb)
Tube thickness limit value min. 4.5 mm - max 6.5 mm (min. 11/64” - max 1/4”)
Cable
cross-section
Recommended
(*)
(**)
L < 5 m
70 mm
2
(AWG 2/0)
50 mm
2
(AWG 1)
2 x 50 mm
2
(2 x AWG 1)
70 mm
2
(AWG 2/0)
2 x 70 mm
2
(2 x AWG 2/0)
70 mm
2
(AWG 2/0)
5.1 < L < 10 m
2 x 50 mm
2
(2 x AWG 1)
70 mm
2
(AWG 2/0)
2 x 70 mm
2
(2 x AWG 2/0)
2 x 50 mm
2
(2 x AWG 1)
2 x 95 mm
2
(2 x AWG 3/0)
2 x 50 mm
2
(2 x AWG 1)
10.1 < L < 20 m
2 x 70 mm
2
(2 x AWG 2/0)
95 mm
2
(AWG 3/0)
2 x 95 mm
2
(2 x AWG 3/0)
2 x 70 mm
2
(2 x AWG 2/0)
2 x 120 mm
2
(2 x AWG 4/0)
2 x 70 mm
2
(2 x AWG 2/0)
MODELS BTQ 2512012 BTQ 2512024 BTQ2514024 BTQ 2524024
Propeller type 2 Counter rotating (technopolymer)
Tunnel Ø
250 mm (9” 27/32 in)
250 mm (9” 27/32 in) 250 mm (9” 27/32 in) 250 mm (9” 27/32 in)
Motor power 6.5 Kw 6.5 Kw 8 Kw 10 Kw
Voltage 12 V 24 V 24 V 24 V
Fuse 500 A CNL DIN 275 A CNL DIN 275 A CNL DIN 500 A CNL DIN
Thrust 120 kgf (265 lb) 120 kgf (265 lb) 140 kgf (308 lb) 240 kgf (529 lb)
Weight 35.5 Kg (78.2 lb) 34.2 Kg (75.4 lb) 34.2 Kg (75.4 lb) 49.1 Kg (108.2 lb)
Tube thickness limit value min. 6.5 mm - max 11 mm (min. 1/4” - max 7/16”)
Cable
cross-section
Recommended
(*)
(**)
L < 5 m
2 x 70 mm
2
(2 x AWG 2/0)
70 mm
2
(AWG 2/0)
70 mm
2
(AWG 2/0)
2 x 50 mm
2
(2 x AWG 1)
5.1 < L < 10 m
2 x 95 mm
2
(2 x AWG 3/0)
2 x 50 mm
2
(2 x AWG 1)
2 x 50 mm
2
(2 x AWG 1)
2 x 70 mm
2
(2 x AWG 2/0)
10.1 < L < 20 m
2 x 120 mm
2
(2 x AWG 4/0)
2 x 70 mm
2
(2 x AWG 2/0)
2 x 70 mm
2
(2 x AWG 2/0)
2 x 95 mm
2
(2 x AWG 3/0)
MODELS BTQ 3025024 BTQ 3027024 BTQ 3030048 BTQ 3030048 NYLON
Propeller type
2 Counter rotating (technopolymer)
2 Counter rotating
(nibral)
2 Counter rotating
(technopolymer)
Tunnel Ø 300 mm (11” 13/16 in) 300 mm (11” 13/16 in) 300 mm (11” 13/16 in) 300 mm (11” 13/16 in)
Motor power 10 Kw 12 Kw 15 Kw 15 Kw
Voltage 24 V 24 V 48 V 48 V
Fuse 400 A CNL DIN 500 A CNL DIN 500 A CNL DIN 500 A CNL DIN
Thrust 250 kgf (551 lb)
270 kgf (595 lb) 300 kgf (661 lb) 300 kgf (661 lb)
Weight 46.7 Kg (102.9 lb) 55.9 Kg (123.2 lb) 66.7 kg (147 lb) 60 kg (132 lb)
Tube thickness limit value min. 9.5 mm - max 13.5 mm (min. 3/8” - max 17/32”)
Cable
cross-section
Recommended
(*)
(**)
L < 5 m
70 mm
2
(AWG 2/0)
95 mm
2
(AWG 3/0)
95 mm
2
(AWG 3/0)
95 mm
2
(AWG 3/0)
5.1 < L < 10 m
2 x 50 mm
2
(2 x AWG 1)
2 x 95 mm
2
(2 x AWG 3/0)
2 x 70 mm
2
(AWG 2/0)
2 x 70 mm
2
(AWG 2/0)
10.1 < L < 20 m
2 x 95 mm
2
(2 x AWG 3/0)
2 x 120 mm
2
(2 x AWG 4/0)
2 x 95 mm
2
(2 x AWG 3/0)
2 x 95 mm
2
(2 x AWG 3/0)
(*) L = positive cable + negative cable
(**) Other solutions are allowed, provided that they are supported by the connecting terminals. Respect minimum area indicated.
