BTQ Series
EN
QUICK BTQSeries INSTALLATION AND USER’S MANUAL - REV003A
7
2.0 - Standard supply and material included in the package
• Thruster
• Drilling template
• Gasket
• O-ring
• Installation and use manual
• Conditions of warranty
2.1 - Tools required for installation
BTQ110/125 • Drill and drill bits Ø 7 mm (9/32”)
• Hollow mill Ø 25 mm (63/64”)
• Male hex.wrenches: 4 mm, 5 mm and 6 mm
• Fork wrench: 10 mm
BTQ140 • Drill and drill bits Ø 7 mm (9/32”)
• Hollow mill Ø 27 mm (1” 1/16)
• Male hex.wrenches: 4 mm, 5 mm and 6 mm
• Fork wrench: 17 mm
BTQ185 • Drill and drill bits Ø 9 mm (3/8”)
• Hollow mill Ø 35 mm (1” 3/8)
• Male hex.wrenches: 5 mm, 6 mm and 8 mm
• Fork wrench: 19 mm
BTQ250 • Drill and drill bits Ø 11 mm (7/16”)
• Hollow mill Ø 46 mm (1” 13/16)
• B00 Hollow mill Ø 82 mm (3” 7/32)
• C00 Hollow mill Ø 120 mm (4” 23/32)
• Male hex.wrenches: 4 mm, 5 mm, 8 mm and 10 mm
• Fork wrench: 24 mm
BTQ300 • Drill and drill bits Ø 15 mm (19/32”)
• Hollow mill Ø 53 mm (2” 3/32)
• Male hex.wrenches: 4 mm, 5 mm, 8 mm and 12 mm
• Fork wrench: 27 mm
2.2 - Recommended Quick
®
accessories not included
• TCD 2022 remote control
• TCD 2042 remote control
• TCD 2044 remote control
• TCD 2062 remote control (with integrated line switch)
• TSC 2000 integrated line switch control
• TMS line switch
• THF3 - THF6 fuse holder
2 - Supply and equipment
3.0 - Important notes
BEFORE USING THE PRODUCT, PLEASE READ THIS USER’S MANUAL CAREFULLY. IF IN DOUBT, PLEASE CONSULT YOUR QUICK® DEALER.
This manual features Warning and/or Caution symbols that are important for safety.
Please follow the instructions provided.
Warning symbol for dangerous
situations.
Caution symbol to prevent direct or
indirect damage to the product.
This manual provides boat manufacturers and nautical equipment installers with instructions on how to assemble the specied
Quick
®
product and operate it correctly.
