QUICK BTQSeries INSTALLATION AND USER’S MANUAL - REV003A
5
1.0 - Technical Data
MODELS BTQ 1102512 BTQ 1253012 BTQ 1254012 BTQ 1403012 BTQ 1404012
Propeller type Single (technopolymer)
Tunnel Ø 110 mm
(4” 21/64)
125 mm
(5”)
125 mm
(5”)
140 mm
(5” 33/64)
140 mm
(5” 33/64)
Motor power 1.3 kW 1.5 kW 2.2 kW 1.5 kW 2.2 kW
Voltage 12 V 12 V 12 V 12 V 12 V
Fuse 130 A CNL DIN 225 A CNL DIN 325 A CNL DIN 150 A CNL DIN 225 A CNL DIN
Thrust 25 kgf (55.1 lb) 30 kgf (66.1 lb) 40 kgf (88.2 lb) 30 kgf (66.1 lb) 40 kgf (88.2 lb)
Weight 9.3 kg (20.5 lb) 10.0 kg (22.0 lb) 10.9 kg (24.0 lb) 11.3 kg (24.9 lb) 12.2 kg (26.8 lb)
Tube thickness limit value
min. 3 mm - max 6.5 mm (min. 1/8” - max 1/4”) min. 4.5 mm - max 6.5 mm
(min. 11/64” - max 1/4”)
Cable
cross-section
Recommended
(*)
(**)
L < 5 m
35 mm
2
(AWG 2)
50 mm
2
(AWG 1)
70 mm
2
(AWG 2/0)
35 mm
2
(AWG 2)
50 mm
2
(AWG 1)
5.1 < L < 10 m
50 mm
2
(AWG 1)
70 mm
2
(AWG 2/0)
2 x 50 mm
2
(2 x AWG 1)
50 mm
2
(AWG 1)
70 mm
2
(AWG 2/0)
10.1 < L < 20 m
70 mm
2
(AWG 2/0)
95 mm
2
(AWG 3/0)
2 x 70 mm
2
(2 x AWG 2/0)
70 mm
2
(AWG 2/0)
95 mm
2
(AWG 3/0)
MODELS BTQ 1805512 BTQ 1805524 BTQ 1807512 BTQ 1807524 BTQ 1809524 BTQ 1809524
Propeller type Single (technopolymer)
Tunnel Ø
185 mm
(7” 18/64)
185 mm
(7” 18/64)
185 mm
(7” 18/64)
185 mm
(7” 18/64)
185 mm
(7” 18/64)
185 mm
(7” 18/64)
Motor power 3.0 kW 3.0 kW 4.0 kW 4.0 kW 6.0 kW 6.0 kW
Voltage 12 V 24 V 12 V 24 V 12 V 24 V
Fuse 250 A CNL DIN 150 A CNL DIN 350 A CNL DIN 250 A CNL DIN 350 A CNL DIN 250 A CNL DIN
Thrust 55 kgf (121.2 lb) 55 kgf (121.2 lb) 75 kgf (165.3 lb) 75 kgf (165.3 lb) 95 kgf (209.4 lb) 95 kgf (209.4 lb)
Weight 16.7 kg (36.8 lb) 16.9 kg (37.2 lb) 17.0 kg 37.5 lb 19.6 kg 43.2 lb 26.6 kg (58.6 lb) 24.2 kg (53.3 lb)
Tube thickness limit value
min. 4.5 mm - max 6.5 mm
(min. 11/64” - max 1/4”)
Cable
cross-section
Recommended
(*)
(**)
L < 5 m
50 mm
2
(AWG 1)
35 mm
2
(AWG 2)
70 mm
2
(AWG 2/0)
50 mm
2
(AWG 1)
2 x 50 mm
2
(2 x AWG 1)
50 mm
2
(AWG 1)
5.1 < L < 10 m
70 mm
2
(AWG 2/0)
50 mm
2
(AWG 1)
2 x 50 mm
2
(2 x AWG 1)
70 mm
2
(AWG 2/0)
2 x 70 mm
2
(2 x AWG 2/0)
70 mm
2
(AWG 2/0)
10.1 < L < 20 m
95 mm
2
(AWG 3/0)
70 mm
2
(AWG 2/0)
2 x 70 mm
2
(2 x AWG 2/0)
95 mm
2
(AWG 3/0)
2 x 95 mm
2
(2 x AWG 3/0)
95 mm
2
(AWG 3/0)
(*) L = positive cable + negative cable
(**) Other solutions are allowed, provided that they are supported by the connecting terminals. Respect minimum area indicated.
