Quick BTR Series - Page 31

BTR Series
EN
MOD. BTR1856512 BTR1856524 BTR1858512 BTR1858524 BTR18510512 BTR18510524
A 722 (28" 27/64) 743 (29" 1/4) 709 (27" 29/32)
801 (31" 17/32) 779 (30" 21/32)
B 300 (11" 13/16) 323 (12" 23/32) 287 (11" 5/16)
384 (15" 1/8) 361 (14" 7/32)
C 370 (14" 9/16)
D 599 (23" 37/16)
E 300 (11" 13/16)
F 150 (5" 29/32)
G 94 (3" 45/64)
H 60 (2" 23/64)
MOD. BTR25012024 BTR25014024 BTR25024024
A 879 (34" 39/64) 908 (35" 3/4)
B 450 (17" 23/32) 515 (20" 9/32)
C 394 (15 33/64) with actuator: 411 (16 3/16)
D 754 (29” 11/16)
E 406 (15" 63/64)
F 200 (7" 7/8)
G 154.5 (6” 5/64)
H 63.5 (2" 1/2)
MOD. BTR30025024 BTR30027024 BTR30030048
A 954 (37" 9/16) 975 (38”3/8) 997 (39" 1/4)
B 462 (18" 3/16) 514 (20" 1/4) 553 (21" 3/4)
C 570 (22" 7/16)
D 859 (33" 13/16)
E 475 (18" 11/16)
F 200 (7" 7/8)
G 149 (5" 7/8)
H 114 (4" 1/2)
QUICK BTR Series INSTALLATION AND USER’S MANUAL - REV 001C
31
14 - Dimensions
BTR 185 Pag.30
BTR 250 Pag.30
BTR 300 Pag.30
