QUICK BTR Series INSTALLATION AND USER’S MANUAL - REV 001C
17
5 - Wiring diagram
M1
A A
S S
SX
+
-
DX
-
M2
RTC R1 ELECTRONIC
BOARD
BATTERY 12/24V
BATTERY
DISCONNECTION
SWITCH
BLACK
FAST-BLOW
FUSE 4A
FUSE SEE
TABLE ON
PAGE 4
SWITCH
RED
BLACK
RED
TO THE SERVICES
BATTERY
TCD
TCD
SPLITTER (OPTIONAL)
EXTENSIONS
(OPTIONAL)
*
*
MOTOR
TO THE SERVICES
BATTERY
ACTUATOR
SWITCH
*
1 2
4
6
5
3
7
FAST-BLOW FUSE
10A
**
THERMAL
PROTECTION
*
COMMON NEGATIVE FOR BATTERY GROUPS.
**
WARNING: IN CASE OF OVERTEMPERATURE, THE THERMAL CUT-OUT ON THE MOTOR WILL TRIGGER AND INTERRUPT THE NEGATIVE CONTACT ON THE CONTACTOR. WAIT FOR THE TIME NEEDED
FOR REACTIVATION.
5.0 - BTR basic system
Example of connection
