42
GB
CHC1202M IT GB - REV005B
Free fall
At times the anchor may have to be lowered by wanting the windlass to free fall (without electrical com-
mand).
The chain counter will measure the length of the chain lowered under these circumstances as well. A win-
dow similar to the one shown below appears during free fall:
MONITORING
The information shown on the monitor line can be changed by pressing and releasing key
=
(SELECT) in
less than one second.
The following data can be displayed: date and time, supply voltage and chain speed.
SPEED 82 M / M
FREE FALL
MON 30 SEP 15:32
STOP
BATTERY 12.8V
STOP
SPEED 0 M/M
STOP
The date and time are stored even when the chain counter is shut off
(it is equipped with a buffer battery).
The precision of the supply voltage reading is ± 1% accurate.
The precision of the chain speed reading is ±1% accurate.
CHAIN COUNTER OPERATION
