54
GB
CHC1202M IT GB - REV005B
SETTINGS MENU - UTILITY
SET DEFAULT
This function allows the user to enter the default values and restart the
chain counter.
The SET DEFAULT window appears as shown below:
SETTINGS MENU - UTILITY
CHECK FLASH (PROGRAM MEMORY)
This function shows the calculated FLASH memory checksum (SUM)
and the one stored during production (TRUE).
SETTINGS MENU - UTILITY
SW VERSION
This function displays the software version installed in the chain counter.
SW VERSION
SW VERSION
VX.X
Go back to UTILITY menu.
SET DEFAULT
ARE YOU SURE?
YES NO
Confirm value.
Select data items from sub-menu.
CHECK FLASH
TRUE: XXXX
SUM: YYYY
CHECK FLASH
Go back to UTILITY menu.
In order for the chain counter to operate properly the two values must
match.
YES or NO can be entered.
SETTING THE CHAIN COUNTER
