Quick MC2 Series - Stabilizer Lifting Procedure

17
EN
INSTALLATION AND USE MANUAL QUICK MC² X3_DC REV001A
DC
DC
5 - Handling and Transportation
5.2 - Lifting the stabilizer
3. Lift the stabilizer with the straps properly secured to the supports on the base. Use spacers for ropes to prevent
damaging cables or connectors.
4. Lift the stabilizer, and remove the screws from the wood base on which the stabilizer is fixed.
NEVER LIFT THE STABILIZER INTO THE CONDITION IN EXAMPLE 5.
3.
5.
4.
