11
EN
INSTALLATION AND USE MANUAL QUICK MC² X3_DC REV001A
2 - Supplied parts
2.1 - Needed accessory and material included in its packaging
Not supplied with the stabilizer
• RC Remote Control MC
2
touch 5", IP66 - It allows you to turn the stabilizer on and off
and monitor its status ( also in multi-station).
Supplied with:
- template for mounting the Remote Control
- J3 RC Extention CAN BUS for the CAN BUS connection to the RC Remote Control MC
2
- CAN 5P T F/F/F connector
- CAN Terminator.
2.2 - Required components, not supplied with the stabilizer
• Differential circuit breaker for connecting the Gyro.
2.3 - Tools needed for installation
• Lifting straps
• Torque wrench.
• Drill & drill bit 9 mm (23/64")
• Fork key 13 mm (33/64")
• Hexagonal key 6 mm (15/64")
MC
²
X3 Quick gyro stabilizer is equipped with all the parts needed for its installation.
2.0 - Package contains the following parts
1 Pre-wired MC
²
X3 Gyro stabilizer
4 Eye bolts for MC
²
X3 stabilizer lifting
1 Template to install the MC
²
X3 stabilizer
8 Screws with resistance category higher than 10.9. Tightening torque 78 Nm - M10.
8 Screws with base plate (optional) with resistance category higher than 10.9. Tightening torque 39 Nm - M8.
1 INSTALLATION AND USE MANUAL
