INSTALLATION AND USE MANUAL QUICK MC² X3_DC REV001A
DC
8 - Electrical connection
8.2 - Connection diagram
RC Remote Control MC
2
STABILIZER
M12 CONNECTOR
5 MALE POLES
CONNECTOR M12
5 MALE POLES
CONNECTOR M12
5-POLE FEMALE
T F/F/F CONNECTOR
5 FEMALE POLES
CAN CABLE 12M
M/M
TERMINATOR
POWER SUPPLY
12 Vdc
FUSE
2A
BATTERY 12 Vdc
-
+
+
-
J1
J1
* CIRCUIT BREAKER
** FUSE
THE USE OF ONE OF THESE TWO COMPONENTS EXCLUDES THE OTHER.
SEE THE "TECHNICAL DATA" TABLE ON PAGE 8
* **
GROUNDING CABLE
(NOT SUPPLIED)
