8
EN
INSTALLATION AND USE MANUAL QUICK MC² X3_DC REV001A
1.0 - Description
The MC
2
series is the result of careful research, aimed at achieving highly competitive performances.
The Quick
®
research and development laboratories have revolutionized the MC
2
series’ concept of operation, by introducing
technical solutions capable of guaranteeing greater safety, more comfort and much higher performances.
The MC
2
series stabilizers are compact and functional.
Quick MC²X3 is useful and effective to improve comfort on board, but it does not eliminate the risks deriving from
harsh atmospheric conditions.
1.1 - Main features
• Maximum performance
• Maximum protection
• Smart and compact design
• High installation exibility
• Dynamic precession control
• Precession lock function from remote panel.
• Equipped with Quick
®
electric motors.
• Low noise emission.
• Overheating protection.
• Thermal protection.
• MC
2
Mobile App to record stabilizer performance (iOS and Andorid)
• Reduced maintenance
1 - Information about the product
1.2 - Technical data
(1) Rated speed: flywheel speed (RPM: Revolutions per minute).
(2) Angular momentum: it quantifies the torque that is necessary to balance the system in the time unit (Newtons meter second).
(3) Output torque: torque generated by the rotor at rated speed (Newtons per meter).
(4) Sea state dependent.
(5) Excluding optional base plate accessory, standard or custom.
MODEL MC² X3 DC
Rated speed (1) 7000 RPM
Angular momentum (2) 643 N·m·s
Output torque (3) 3900 N·m
Spool-up time to rated RPM 15 min
Spool-up time to stabilization 10 min
Power absorbed (4) 650 ÷ 900 W max
AC Input voltage 12 Vdc
Circuit Breaker 80 A
Fuse 50 A
Frequency 50-60 Hz
Noise output < 70 dB
Ambient air temperature
from-10°C a +55°C
(14°F to 131°F)
Weight (5) 131 kg (288,8 lb)
