Quickie F35 R2 - 14 Specification Sheets

Quickie F35 R2 Rev.E 31
Model: Quickie F35 R2
14.0 Specification sheets (EN 12184 & ISO 7176-15)
Sunrise Medical S.L.
Polígono Bakiola, 41
48498 Arrankudiaga – Vizcaya
España
Tel.: +34 (0) 902142434
Fax: +34 (0) 946481575
www.sunrisemedical.com
Operating temperature: - 25°C to 50°C
Storage temperature: -40°C to 65°C
Moisture resistance: IPx4
No restrictions on humidity and air pressure
Maximum occupant mass:
120kg user weight.
The wheelchair Quickie
F35 R2 conforms to the
following standards:
a) requirements and test
methods for static, impact
and fatigue strengths
(ISO 7176-8)
b) power and control
systems for electric
wheelchairs requirements
and test methods (ISO
7176-14)
c) climatic test in
accordance with ISO
7176-9
d) requirements for
resistance to ignition in
accordance with
ISO 7176-16
e) the product is specified
as a Class B power chair
f) all materials used on
this product conform to
EN1021 parts 1 and 2.
ISO 7176-15 MIN. MAX. COMMENTS
Overall length (Inc. Leg rest) 1060mm 1060mm 70° hangers
Overall width 600mm
Total mass (with batteries) 67.1kg
Folded Length 860mm* 1050mm * Without legrests
Folded Width 335mm
Folded Height 645mm* 920mm *Without backrest
Mass of the heaviest part - 34.0kg* *Batteries, Legrests and
Footrests removed
Static stability downhill - 10°
Static stability uphill - 10°
Static stability sideways - 10°
Energy consumption (max. range) - 25km 6kph motor & 100kg user
Dynamic stability uphill - 10° Max. Safe Slope = 10°
(18%)
Obstacle climbing (with kerb climber) 50mm 100mm* * With Kerb Climber
Max. speed forward 6kph
Min. brake distance from max. speed - - Depends on programming
Seat plane angle 0° 3° Set without tools
Effective seat depth - 430mm
Effective seat width 430mm 520mm Via armrests
Seat surface height at front edge - 510mm
Back rest angle 8°
Back rest height 425mm
Footrest to seat distance 420mm 490mm
Leg to seat surface angle 70° -
Armrest to seat distance 180mm 300mm
Min. turning radius 900mm 70° Hanger
Nominal battery voltage 24V Deep Cycle Mobilty
Battery Capacity 40 Ah 50Ah Deep Cycle Mobilty
Battery cut-off voltage 16V
Battery fusible links - 100A In-line fuse on each battery
User Weight 120kg
EN 12184 MIN. MAX. COMMENTS
Max. kerb height 50mm (100mm) (With kerb climber)
Turning space/Reversing width 900mm -
Speed control operation force 2N
Direction control operation force 1N
NOTE: Some of the options and measures may be not available in all countries.
