Quicksilver 675PH — System & Component Overview and Operaon
Black Water System
Overboard discharge
Holding tank to pumpout hose
Pumpout deck plate
Holding tank to vent lter hose
Vent lter
Vent lter to tank vent thru hull hose
Tank vent thru hull
Toilet water pickup
Pickup to toilet water hose
Toilet
Toilet to holding tank hose
Holding tank
Holding tank to macerator hose
Macerator
Macerator to overboard discharge hose
This boat is equipped with an overboard discharge seacock.
Some countries levy severe penales for discharging raw
sewage and solid waste in waters where it is prohibited. Be
aware of local environmental laws, and respect codes of
good pracce. Demonstrang that the macerator is disabled
by locking the system and/or removing the seacock handle
may avoid a ne.
The toilet water pickup valve should always be in the closed
posion when not in use. Failure to do so could result in
ooding, property damage, and/or loss of life.
When not in use, the toilet wall and toilet lid should be installed in place, covering the toilet.
Refer to the toilet owner's manual in regards to specic operaon of the toilet. When ushing the
toilet, it will take approximately 21 complete up/down strokes for the contents to reach the holding
tank.
Macerator
The macerator gives the boat operator the means of discharging the holding tank directly
overboard through a seacock in the boom of the hull. The macerator control is located inside the
cabin on the port pilaster. Since direct overboard discharge is prohibited in many areas, the macerator
seacock is normally closed.
