Quicksilver 675PH — System & Component Overview and Operaon
34
Vision from the exterior helm staon is limited. Maintain a
lookout as required. Do not operate at planning speeds
from the exterior helm.
DO NOT TURN THE STEERING WHEEL AT THE HELM
THAT DOES NOT HAVE FULL CONTROL OF THE BOAT.
Pressing this buon twice will immediately transfer throle and shi control. The “Acve Helm”
panel will illuminate and two loud beeps will be heard. This completes the helm control transfer.
To return control back to the main helm, move the control to neutral. Go to the main helm, press
and release the “Throle Only” buon on the control handle twice.
Pressing this buon twice will immediately transfer throle and shi control. The “Acve Helm”
panel will illuminate and two loud beeps will be heard. This completes the helm control transfer.
The steering system is independent of the helm selector switch and will operate at all mes. DO NOT
TURN THE STEERING WHEEL AT THE HELM THAT DOES NOT HAVE FULL CONTROL OF THE BOAT!
Hydraulic Steering
The exterior helm comes with an addional steering helm, steering wheel, and steering hoses that
connects to the base steering system. The operaon of the system is similar, where when you turn
the steering wheel the helm pump forces hydraulic uid through hoses to and from the steering
cylinder which is connected to the ller arm on the engine. Even though the helms are connected,
the steering wheels will not rotate together when one wheel is turned.
Maintenance
A hydraulic steering system rarely needs to be relled aer the system is bled. However, if you ever
need to add uid to the system, refer to the steering manufacturer’s manual for complete
instrucons.
REFER TO OWNER’S MANUAL PACKAGE FOR INSTRUCTIONS AND WARRANTY INFORMATION.
Dual Helm Hydraulic Steering
Steering wheel
Main helm pump
Hydraulic uid lines
Exterior helm pump
Steering cylinder
