Appendix A - Dimensional Drawings & Technical Data
QCS100
ContainEr CapaCity 2.64 gallonS
filling volumE witH prE-SEpartion 1.14 gallonS
CondEnSatE fEEd (HoSE) 2 x ½" (di = 10 mm)
watEr outlEt (HoSE) ½" (di=10 mm)
wEigHt Empty 8.8 lB
min./max. tEmpEraturE + 41 ... +140 °f
maximum opErating prESSurE at inlEt 232 pSig*
prEfiltEr 0.66 gal
main filtEr 0.53 gal
* A high-pressure relief chamber should be used in the case of higher pressures.
* Para presiones superiores, usar cámara de relajación de alta presión.
Quincy Compressor-QCS High Efficiency Emulsion Separators 27
