Appendix A - Dimensional Drawings & Technical Data
Qcs 900 1600
C
ontainEr CapaCity 30.5 gal 60.3 gal
filling volumE 19.2 gal 36.2 gal
CondEnSatE fEEd (HoSE) 3 x ½" (di = 13 mm)/1 x 1" (di = 25 mm)
watEr outlEt (HoSE) 1" (di=25 mm)
SErviCE valvE (HoSE) ¼" (di=13 mm)
oil CollECtor 2 x 2.6 gal 2 x 5.3 gal
wEigHt Empty 70.55 lB 92.59 lB
minimum/maximum tEmpEraturE +41°f/+140°f
maximum opErating prESSurE at inlEt* 232 pSig
prEfiltEr 4.89 gal 9.6 gal
main filtEr 5.42 gal 10.65 gal
* A high-pressure relief chamber should be used in the case of higher pressures.
Quincy Compressor-QCS High Efficiency Emulsion Separators 31
