COMPONENT DESCRIPTION
P O R
I T A
E N G E S P
29
30
4
3
2
1
28
27
5
6
26
7
8
25
9
24
23
22
17 21
10
12
13
14 15
11
16 18 19 20
1.- Frame
2.- Charging point
3.- Saddle
4.- Seatpost
5.- Seatpost locker
6.- Rear Wheel brake
7.- Elastic band (s/model)
8.- Rack (s/mode)
9.- Rear Wheel mudguard (s/model)
10.- Rear wheel
11.- Rear wheel hub - Gear
12.- Chain / Belt (s/modelo)
13.- Leg (s/model)
14.- Crank
15.- Folding pedal
16.- Control unit (built in the frame)
17.- Locker and folding mechanism (on the
other side, not seen)
18.- Battery (built in the frame)
19.- Front wheel
20.- Front wheel hub ʹ Motor
21.- Fork
22.- Front Wheel brake
23.- Front Wheel mudguard
(s/model)
24.- Front light (s/modelo)
25.- Folding handlebar mechanism locker
26.- Bar
27.- Brake lever
28.- Shifter (s/model)
29.- Control unit
30.- Stem (s/model)
