1
3
2
1. Tap through the work top
Push the tap through the hole in the work
top. Note: When tting the tap in a 32 mm
hole, the black plastic ring needs to be
removed from the tap rst.
2. Secure the tap
Set the tap to the desired position and
secure it with the metal ring and threaded
ring supplied.
3. Secure the screws
Tighten the screws in the threaded ring.
Fitting Nordic single tap
• The total length of the hose between the boiling-water tap and tank is only 70 cm. The tank
must therefore be tted close to the tap. Extension hoses are available in dierent lengths but
are not normally required.
• The small bre washers supplied with the tap rings are not required yet at this point. One will
be used for connecting the tap and tank hose (see section E), the second one is a spare.
B
1
