R82 Rabbit - CHEST SUPPORT

17
D
A
C
B
G
B
CHEST SUPPORT
We recommend to mount the chest support as
the final equipment. Follow the description below
to mount the chest support correctly:
* Mount the top part (A) in the top of the centre
bar and fasten with the enclosed 5 mm allen
key.
* Mount the chest support in the hole in the
centre bar and fasten with the handle (B).
* Loosen the screws (C) and adjust the chest
support sidewise and in height. Fasten all
screws in the desired position.
Max. height! (D)
The max. height indication on the chest
support bar must not go higher than the
top of the centre bar - not the top of any
extra bars from e.g. the tray.
GB
"PONY" CHEST
SUPPORT
The "Pony" chest support is mounted in the
same way as the standard chest support
(Mentioned above).
