SWING-AWAY SIDE
SUPPORTS
Wombat size 1+2:
Remove the back cushion and mount the side
support in the slots in the back, using the enclo
-
sed screws and the 5 mm Allen key (A). Do not
use the long screws.
Push down the red button (B) to swing-away the
side support.
Wombat size 3
:
The adjustable swing side support is fitted into
the groove at the back of the chair (C). Secure
the long screws one by one to grooves (D) at
the rear of the back support. Place the nuts one
by one in the small hole at the front of the back
support. Make sure that the first screw passes
through the groove plate and is properly threa
-
ded into the nut before securing the next screw.
Do not use the short screws.
It is recommendable to oil the swing away
parts occasionally.
GB
A
B
C
D
