6. Quick Reference Table
Key
• Instruction: The mnemonic syntax of the instruction.
• Opcode: The binary bytes that represent the instruction.
• Clock cycles: The number of clock cycles that the instruction takes to complete. The numbers in
parenthesis are a breakdown of the total clocks. For more information, please see Table 1: "Clocks
Breakdown" on page 7.
• A: How the ALTD prefix affects the instruction. For more information, please see Table 2: "ALTD
(“A” Column) Symbol Key" on page 8.
• I: How the IOI or IOE prefixes affect the instruction. For more information, please see Table 3: "IOI
and IOE (“I” Column) Symbol Key" on page 8. A “b” in this column indicates that the prefix applies to
both source and destination.
• S; Z; LV; C: These columns denote how the instruction affects the flags. For more information, please
see Table 4: "Flag Register Key" on page 8.
• Operation: A symbolic representation of the operation performed.
• N/M/P: An “N” in this column indicates that the instruction has been added to the Z180 instruction
set by the Rabbit 2000/3000. An “M” indicates that this instruction is from the Z180, but has been
modified. A “P” indicates a privileged instruction.
Instruction
Opcode
byte 1
Opcode
byte 2
Opcode
byte 3
Opcode
byte 4
Clock cycles A I S Z LV C Operation N/M/P
ADC A,(HL) 10001110 5 (2,1,2) fr s * * V * A=A+(HL)+CF
ADC A,(IX+d) 11011101 10001110 ----d--- 9 (2,2,2,1,2) fr s * * V * A=A+(IX+d)+CF
ADC A,(IY+d) 11111101 10001110 ----d--- 9 (2,2,2,1,2) fr s * * V * A=A+(IY+d)+CF
ADC A,n 11001110 ----n--- 4(2,2) fr * * V * A=A+n+CF
ADC A,r 10001-r- 2 fr * * V * A=A+r+CF
ADC HL,ss 11101101 01ss1010 4(2,2) fr * * V * HL=HL+ss+CF
ADD A,(HL) 10000110 5 (2,1,2) fr s * * V * A=A+(HL)
ADD A,(IX+d) 11011101 10000110 ----d--- 9 (2,2,2,1,2) fr s * * V * A=A+(IX+d)
ADD A,(IY+d) 11111101 10000110 ----d--- 9 (2,2,2,1,2) fr s * * V * A=A+(IY+d)
ADD A,n 11000110 ----n--- 4(2,2) fr * * V * A=A+n
ADD A,r 10000-r- 2 fr * * V * A=A+r
ADD HL,ss 00ss1001 2 fr - - - * HL = HL + ss
ADD IX,xx 11011101 00xx1001 4(2,2) f - - - * IX = IX + xx
ADD IY,yy 11111101 00yy1001 4(2,2) f - - - * IY = IY + yy
ADD SP,d 00100111 ----d--- 4(2,2) f - - - * SP = SP + d N
ALTD 01110110 2 - - - -
alternate register destination
for next instruction
N
AND (HL) 10100110 5 (2,1,2) fr s * * L 0 A=A&(HL)
AND (IX+d) 11011101 10100110 ----d--- 9 (2,2,2,1,2) fr s * * L 0 A=A&(IX+d)
AND (IY+d) 11111101 10100110 ----d--- 9 (2,2,2,1,2) fr s * * L 0 A=A&(IY+d)
AND HL,DE 11011100 2 fr * * L 0 HL = HL & DE N
