Rabbit 2000 - 3.2 Memory Mapping

Instruction Reference Manual 17
Description
The data in the word register HL is summed with the data in the word register ss (any of the word registers
BC, DE, HL, or SP). The result is stored in HL.
ADD HL,ss
Opcode Instruction Clocks Operation
——
09
19
29
39
ADD HL,ss
ADD HL,BC
ADD HL,DE
ADD HL,HL
ADD HL,SP
2
2
2
2
2
HL = HL + ss
HL = HL + BC
HL = HL + DE
HL = HL + HL
HL = HL + SP
Flags ALTD I/O
S Z L/V C F R SP S D
- - - • • •
