Rabbit 2000 - 3.5 Interrupt Structure

Instruction Reference Manual 37
Description
The Interrupt Priority Register, IP is an 8-bit register that forms a stack of the current priority and the other
previous 3 priorities. IPSET 0 forms the lowest priority; IPSET 3 forms the highest priority. These instruc-
tions are privileged. They are implemented for the Rabbit and are not available for the Z180.
• IPSET 0: The IPSET 0 instruction shifts the contents of the register holding the previous pri-
orities 2-bits to the left, then sets the Interrupt Priority Register (bits 0 and 1) to 00.
• IPSET 1: The IPSET 1 instruction first shifts the contents of the register holding the previous
priorities 2-bits to the left, then sets the Interrupt Priority Register (bits 0 and 1) to 01.
• IPSET 2: The IPSET 2 instruction shifts the contents of the register holding the previous pri-
orities 2-bits to the left, then sets the Interrupt Priority Register (bits 0 and 1) to 10.
• IPSET 3: The IPSET 3 instruction shifts the contents of the register holding the previous pri-
orities 2-bits to the left, then sets the Interrupt Priority Register (bits 0 and 1) to 11.
IPSET 0
IPSET 1
IPSET 2
IPSET 3
Opcode Instruction Clocks Operation
ED 46 IPSET 0 4 (2,2) IP = {IP[5:0], 00}
ED 56 IPSET 1 4 (2,2) IP = {IP[5:0], 01}
ED 4E IPSET 2 4 (2,2) IP = {IP[5:0], 10}
ED 5E IPSET 3 4 (2,2) IP = {IP[5:0], 11}
Flags ALTD I/O
S Z L/V C F R SP S D
- - - -
Processor Priority Effect on Interrupts
0 All interrupts, priority 1,2 and 3 take place after
execution of current non privileged instruction.
1 Only interrupts of priority 2 and 3 take place
after execution of current non privileged
instruction.
2 Only interrupts of priority 3 take place after
execution of current non privileged instruction.
3 All interrupts are suppressed
(except the RST instruction).
