116 Rabbit 2000 Microprocessor
RRC (HL) 11001011 00001110 10 (2,2,1,2,3) f b * * L * (HL) = {(HL)[0],(HL)[7,1]}; CY = (HL)[0]
RRC (IX+d) 11011101 11001011 ----d--- 00001110 13 (2,2,2,2,2,3) f b * * L *
(IX+d) = {(IX+d)[0],(IX+d)[7,1]};
CY = (IX+d)[0]
RRC (IY+d) 11111101 11001011 ----d--- 00001110 13 (2,2,2,2,2,3) f b * * L *
(IY+d) = {(IY+d)[0],(IY+d)[7,1]};
CY = (IY+d)[0]
RRC r 11001011 00001-r- 4(2,2) fr * * L * r = {r[0],r[7,1]}; CY = r[0]
RRCA 00001111 2 fr - - - * A = {A[0],A[7,1]}; CY = A[0]
RST v 11-v-111 8 (2,2,2,2) - - - -
(SP-1) = PCH; (SP-2) = PCL;
SP = SP - 2; PC = {R, 0, v, 0000}
SBC A,(HL) 11011101 10011110 ----d--- 9 (2,2,2,1,2) fr s * * V * A=A-(IX+d)-CY
SBC (IX+d) 11111101 10011110 ----d--- 9 (2,2,2,1,2) fr s * * V * A=A-(IY+d)-CY
SBC (IY+d) 10011110 5 (2,1,2) fr s * * V * A=A-(HL)-CY
SBC A,n 11011110 ----n--- 4(2,2) fr * * V * A=A-n-CY
SBC A,r 10011-r- 2 fr * * V * A=A-r-CY
SBC HL,ss 11101101 01ss0010 4(2,2) fr * * V * HL = HL - ss - CF
SCF 00110111 2 f - - - 1 CF = 1
SET b,(HL) 11001011 11-b-110 10 (2,2,1,2,3) b - - - - (HL) = (HL) | bit
SET b,(IX+d) 11011101 11001011 ----d--- 11-b-110 13 (2,2,2,2,2,3) b - - - - (IX+d) = (IX+d) | bit
SET b,(IY+d) 11111101 11001011 ----d--- 11-b-110 13 (2,2,2,2,2,3) b - - - - (IY+d) = (IY+d) | bit
SET b,r 11001011 11-b--r- 4(2,2) r - - - - r=r|bit
SLA (HL) 11001011 00100110 10 (2,2,1,2,3) f b * * L * (HL) = {(HL)[6,0],0}; CY = (HL)[7]
SLA (IX+d) 11011101 11001011 ----d--- 00100110 13 (2,2,2,2,2,3) f b * * L * (IX+d) = {(IX+d)[6,0],0}; CY = (IX+d)[7]
SLA (IY+d) 11111101 11001011 ----d--- 00100110 13 (2,2,2,2,2,3) f b * * L * (IY+d) = {(IY+d)[6,0],0}; CY = (IY+d)[7]
SLA r 11001011 00100-r- 4(2,2) fr * * L * r = {r[6,0],0}; CY = r[7]
SRA (HL) 11001011 00101110 10 (2,2,1,2,3) f b * * L * (HL) = {(HL)[7],(HL)[7,1]}; CY = (HL)[0]
SRA (IX+d) 11011101 11001011 ----d--- 00101110 13 (2,2,2,2,2,3) f b * * L *
(IX+d) = {(IX+d)[7],(IX+d)[7,1]}; CY =
(IX+d)[0]
SRA (IY+d) 11111101 11001011 ----d--- 00101110 13 (2,2,2,2,2,3) f b * * L *
(IY+d) = {(IY+d)[7],(IY+d)[7,1]}; CY =
(IY+d)[0]
SRA r 11001011 00101-r- 4(2,2) fr * * L * r = {r[7],r[7,1]}; CY = r[0]
SRL (HL) 11001011 00111110 10 (2,2,1,2,3) f b * * L * (HL) = {0,(HL)[7,1]}; CY = (HL)[0]
SRL (IX+d) 11011101 11001011 ----d--- 00111110 13 (2,2,2,2,2,3) f b * * L * (IX+d) = {0,(IX+d)[7,1]}; CY = (IX+d)[0]
SRL (IY+d) 11111101 11001011 ----d--- 00111110 13 (2,2,2,2,2,3) f b * * L * (IY+d) = {0,(IY+d)[7,1]}; CY = (IY+d)[0]
SRL r 11001011 00111-r- 4(2,2) fr * * L * r = {0,r[7,1]}; CY = r[0]
SUB (HL) 10010110 5 (2,1,2) fr s * * V * A=A-(HL)
SUB (IX+d) 11011101 10010110 ----d--- 9 ( 2,2,2,1,2) fr s * * V * A=A-(IX+d)
SUB (IY+d) 11111101 10010110 ----d--- 9 ( 2,2,2,1,2) fr s * * V * A=A-(IY+d)
SUB n 11010110 ----n--- 4(2,2) fr * * V * A=A-n
SUB r 10010-r- 2 fr * * V * A=A-r
XOR (HL) 10101110 5 (2,1,2) fr s * * L 0 A=[A&~(HL)]|[~A&(HL)]
XOR (IX+d) 11011101 10101110 ----d--- 9 (2,2,2,1,2) fr s * * L 0 A=[A&~(IX+d)]|[~A&(IX+d)]
XOR (IY+d) 11111101 10101110 ----d--- 9 (2,2,2,1,2) fr s * * L 0 A=[A&~(IY+d)]|[~A&(IY+d)]
XOR n 11101110 ----n--- 4(2,2) fr * * L 0 A=[A&~n]|[~A&n]
XOR r 10101-r- 2 fr * * L 0 A=[A&~r]|[~A&r]
Instruction
Opcode
byte 1
Opcode
byte 2
Opcode
byte 3
Opcode
byte 4
Clock cycles A I S Z LV C Operation N/M/P
