RaceChip RS - Step 3: Connection to common rail sensor

C
3 Installation
1
A
Step 3 of 7 – Connection to common rail sensor
Common rail connection
• First locate the common rail sensor connection in your engine bay.
• The common rail sensor connection is located either at one of the ends of or

• TT
always lead directly from the injection system to the cylinders, i.e. they can be
traced back from the engine block.
Common rail
connection
Setup illustration
Cable with disconnected
stock plug
Cable from the
RaceChip
Common rail connection
