6.2 Permissible roller shutter belts
i
ATTENTION!
The RolloTron Basic 1100 may be damaged if exces-
sively long belts are used.
Only use belts of the permissible lengths.
Table 1: Permissible roller shutter belts
RolloTron:
Item no.:
Basic
1823 45 19
Belt width:
Belt thick-
ness:
Maximum belt length
23 mm (Standard belt)
1.0 mm 7.6 m
1.3 mm 6.2 m
1.5 mm 5.2 m
Table 2: Permissible shutter surface area (m
2
)
Roller shutter type: Weight/m
2
Permissible shutter surface area
(m
2
)
Plastic roller shutters (4.5 kg/m
2
) Approx. 6 m
2
Aluminium and wooden roller
shutters
(10.0 kg/m
2
) Approx. 3 m
2
i
The specifications are intended for guidance
only and apply to an ideal installation situa-
tion.
The actual values may vary due to local
conditions.
