64
EN
9.1 Connecting the connecting cable to the RolloTron Basic 1100
WARNING!
A damaged connecting cable may cause a short
circuit.
◆ Ensure that the connecting cable is laid safely.
◆ The connecting cable muse not be pinched or dam-
aged when screwing on the RolloTron Basic 1100.
Cable duct
i
2. Lay the connecting cable in the cable duct of the
RolloTron Basic 1100.
Traction relief
3. Finally, screw on the traction relief mechanism with
the screws provided.
