66
EN
4. Next, draw-in the belt into the RolloTron Basic 1100
from the top.
Feed the belt into the device, as shown in the image,
and slide it over the fastening hook from above.
5. Re-insert the mains plug into the socket.
6. Press the Up button until the belt has fully wound
once around the reel.
7. Pull the belt tight when winding, so that the deflection
roller turns at the same time.
8. Remove the mains plug again from the socket.
9. Finally, place the provided reel compartment cover onto
the reel compartment.
Pull the belt over the
fastening hook
10. Drawing in and fastening the belt
Reel compartment
cover
Belt path
in the device
i
